SR 580
Art.nr. H06-8012
SR 500 HD Fan unit UK
Art.nr. H06-0118HD
Easily operated battery powered fan with particle- or combination filters.
The SR 500 is a battery-powered fan that, together with a filter and an approved head top, is included in the
Sundström fan-assisted respiratory protective device systems. The SR 500 can be used as an alternative to
filter respirators in all situations in which these are recommended. This applies particularly to work that is hard,
warm or of long duration.
The human interface may consist of a hood, face shield, half mask or full face mask. The fan is equipped with
a filter, and the filtered air is fed through a hose to the human interface. The pressure then generated prevents
surrounding pollutants from penetrating into the mask.
- Number
- H06-0118HD
- Color
- Blue, Black
- Shelf life (years)
- 5
- Country of manufacture
- Sweden
- Operating temp.
- -10 – +55 °C, < 90 % RH
- Storage temp.
- -20 – +40 °C, < 90 % RH
- Model
- SR 500 HD
- Assign. protection factor
- 40 (TH3), 40 (TM3)
- Nom. protection factor
- 500 (TH3), 2000 (TM3)
- Cell type
- Li-Ion 14,4V 3,5 Ah
- Approval
- EN 12941:1998 + A2:2008, EN 12942:1998 + A2:2008
- Directive 1
- (EU) 2016/425 PPE
